SolidCAMCAD Suite 2024

SolidCAMCAD Standalone - CAM-system with embedded CAD-system (does not require pre-installed SolidWorks or another CAD-system) This system is a complete solution for automating metal-working production. Using the wide range of strategies offered by Turning, Milling, Turning, Milling and EDM, the technologist can quickly prepare the necessary set of control programs for machining the product.

SolidCAM
2.5-axis milling functionality
SolidCAM provides high efficiency and precision 2.5-axis milling of parts. It supports various processing strategies for elements such as contour, selection (with islands) and groove, as well as various types of hole machining: drilling, countersinking, thread cutting, etc. The system has a wide range of 2.5-axis machining capabilities for analytic surfaces.
3-axis milling
SolidCAM provides a wide range of tools that can be effectively used for processing products with complex geometry (dies, molds) and prismatic parts. As a geometry for 3-axis machining, a three-dimensional surface or solid model is used. The system supports various types of roughing and finishing strategies, such as raster processing with a specified or automatically defined raster angle, equidistant processing, projection processing, processing on waterlines, etc.

In addition to the already listed features of 2,5- and 3-axis machining, SolidCAM offers tools for identifying and refining sections that were not processed at previous transitions. It is possible to create a database of typical technological processes. Once created, such a parameterized technological process can be repeatedly used in the future, which significantly reduces preparation time, increases the reliability of the developed programs, unifies the style of technological development, guarantees the use of only optimal processing technologies and ensures the independence of production from the human factor. Lack of slaughter is guaranteed by the availability of means of control and visualization of mechanical processing.

Multi-axis processing
SolidCAM offers various tools for creating multi-axis machining control programs on 4- and 5-axis machining centers. The model is installed in a user-defined machining plane, after which the system automatically calculates all the necessary offset and rotation parameters for the part zero. As a result, the preparatory-final transition time is significantly reduced and processing accuracy is improved.

Turning and turning milling
SolidCAM has a wide range of functions to automate the creation of control programs for turning and turning and milling. SolidCAM supports various types of tools, which allows you to effectively produce longitudinal turning, trimming the ends, grooving, etc. In addition, SolidCAM allows you to automatically produce rough and finishing machining of complex contours. The support of the rotating tool allows you to perform milling and drilling transitions on the machining centers.

Electroerosive treatment
SolidCAM's suite of wire EDM strategies allows the processing of external and internal contours with a constant and variable angle of inclination. The possibility of 4-axis machining. A special algorithm prevents the fall of the processed material. SolidCAM provides the user with the means to control the physical processing parameters throughout the entire wire path.

Note
Do not install this program on a computer with SolidWorks installed.
SolidCAMCAD Suite 2024 does not require pre-installed SolidWorks as it contains its own built-in
SolidWork 2024 OEM
